Suction Filters
| TYPE NUMBER | CONNECTIONS Inches | FILTER AREA Square Inches | DEMENSIONS Inches | SHIPPING WEIGHT Lbs. | |||
|---|---|---|---|---|---|---|---|
| WITHOUT Access Valve | WITH Access Valve | OVERALL LENGTH | SOCKET DEPTH | SHELL DIAMETER | |||
| Types WITH the Optional Relief Feature | |||||||
| SF-283-F | - | 3/8 SAE | 28 | 8.78 | - | 3.0 | 2-1/4 |
| - | SF-285-T | 5/8ODF | 8.34 | 0.62 | |||
| - | SF-286-T | 3/4 ODF | 8.79 | 0.69 | |||
| - | SF-287-T | 7/8 ODF | 8.93 | 0.75 | |||
| - | SF-288-T | 1-1/8 ODF | 9.51 | 0.91 | |||
| - | SF-489-T | 1-1/8 ODF | 48 | 12.42 | 0.91 | 3 | |
| - | SF-4811-T | 1-3/8 ODF | 13.10 | 0.97 | |||
| - | SF-4813-T | 1-5/8 ODF | 13.44 | 1.09 | |||
