제품 사양표
| VAVLE SERIES | TYPE | STANDARD CONNECTIONS Inches | PORT SIZE Inches | MOPD psi* | MRP psi* | STANDARD COIL RATINGS | ||
|---|---|---|---|---|---|---|---|---|
| VOLTS/CYCLES | WATTS | COIL | ||||||
| B5D | B5D5B | 5/8 | 0.625 | 400 | 650 | 24/50-60 120/50-60 208-240/50-60 120-208-240/50-60 |
10 | MKC-1 |
| B5D5C | ||||||||
| 8D | 8D7B | 7/8 | 3/4 | 300 | 450 | |||
| 8D7C | ||||||||
| 8D9B | 1-1/8 | |||||||
| 8D9C | ||||||||
| 12D | 12D11B | 1-3/8 | 1-1/4 | |||||
| 12D11C | ||||||||
| 12D13B | 1-5/8 | |||||||
| 12D13C | ||||||||
| 12D17B | 2-1/8 | |||||||
| 16D | 16D17B | 2-1/8 | 2 | |||||
| 16D17C | ||||||||
